Introduction to Linux

Note

While you will be able to complete most of your coursework in your own computer, you must work through this tutorial on a CS machine, either by going to the Computer Science Instructional Laboratory (CSIL) in the first floor of Crerar Library, or by connecting remotely to a CS environment using a virtual desktop.

Please note that, during the first week of the quarter, we will be reserving the CSIL labs at several times for students to work through this tutorial. At those times, a TA will be present to help with any issues or questions you may have.

Linux is an operating system much like macOS or Windows. It has windows, programs, web browsers, and so on. Files are stored in directories (folders) that, in turn, are stored in other directories. Although you can access Linux’s features using your mouse, as you perform more and more complex tasks, you will find that using the mouse is ineffective. Linux allows us to interact with the computer entirely through text using a program called the terminal. (Mac provides a similar terminal application, and there are ways to use text-based commands on Windows too. But, Linux provides the lowest barrier to entry.) In this tutorial you will learn how to use the terminal to perform some basic operations in Linux. You will need these skills for the rest of your time at UChicago.

We show many examples of sample output below. The output you see when you run the commands may vary a bit.

Objectives

1. Learn basic terminal commands and how to work with a text editor

2. Become familiar with the Linux environment

3. Learn to run a Python program from the command-line

4. Learn about redirection and pipes

5. Learn about file permissions

Terminal/Shell

On your personal computer, you probably navigate your hard drive by double clicking on icons. While convenient for simple tasks, this approach is limited. For example, imagine that you want to delete all of the music files over 5 MB that you haven’t listened to in over a year. This task is very hard to do with the standard double-click interface but is relatively simple using the terminal.

To start a terminal (in either CSIL or the Virtual Desktop), click on the Application icon (3x3 grid of dots) at the bottom left of the screen. Then, type “terminal” in the input box. Click the “terminal” icon to open a terminal window. You can also use the keyboard shortcut: Ctrl+Alt+t.

A terminal window will open and you will see text of the form:

username@computer:~$

where username has been replaced by your CNetID and computer is the name of the machine you happen to be using. This string is called the prompt. When you start typing, the characters you type will appear to the right of the $.

The program that runs within a terminal window and processes the commands the you type is called a shell. We use bash, which is the default shell on most Linux distributions, but there are other popular shells, such as ksh, tcsh, etc.

The procedure for completing this tutorial is as follows. For each section, read through the explanatory text and the examples. Then, try these ideas by doing the exercises listed at the bottom of the section.

Navigating the File System

Files in Linux are stored in directories/folders, just like in macOS/Windows. Directories can hold files or other subdirectories and there are special directories for your personal files, your Desktop, etc.:

Name	Linux	Mac	Windows
Root directory	/	/	C:\
Home directory	/home/username	/Users/username	C:\Documents and Settings\username

Note

The machine you are using (either a CSIL machine or a Virtual Desktop) is connected to a network file system. This means that there is effectively one very large hard drive shared by all the CS machines, and that you will have access to those files regardless of what machine you use. For example, if you create some files while logged into a CSIL machine, and then sit at a different CSIL machine the next day (or use the Virtual Desktop), you will see the exact same files there.

The figure above illustrates how Linux organizes the file system. Your own computer might have a slightly different organization (e.g., you might replace / with C:), but the idea is the same.

For the above and from this point forward, consider that the text “username” is replaced with your own actual username, which is just your CNetID.

Show Files

The terminal will start in your home directory, /home/username/, which is a special directory assigned to your user account. Any CS machine that you use (either in CSIL or remotely) will automatically connect to your home directory and all files that you created or changed in previous work sessions will be available to you.

Two very useful commands are pwd and ls:

pwd	Prints your current working directory - tells you where you are in your directory tree.
ls	Lists all of the files in the current directory.

The following is an example using these two commands in a terminal window:

username@computer:~$ pwd
/home/username/
username@computer:~$ ls
Desktop  Documents  Downloads  Music  Pictures  Public  Templates  Videos
username@computer:~$

Try these commands yourself to verify that everything looks similar.

Notice that the directory path and list of files that you see if you open your home folder graphically are identical to those provided by pwd and ls, respectively. The only difference is how you get the information, how the information is displayed, and how easy it is to write a script that, say, processes all the Python files in a directory.

Change Directory

cd <path-name>	change to the directory path-name
cd ..	move up/back one directory
cd	move to your home directory

How can we move around in the file system? If we were using a graphical system, we would double click on folders and occasionally click the “back” arrow. In order to change directories in the terminal, we use cd (change directory) followed by the name of the destination directory. (A note about notation: we will use text inside angle brackets, such as <path-name> as a place holder. The text informally describes the type of value that should be supplied. In the case of <path-name>, the desired value is the path-name for a file or directory. More about path-names later.) For example if we want to change to the Desktop directory, we type the following in the terminal:

cd Desktop

Here is an example of changing to the desktop directory in the terminal. We use pwd and ls to verify where we are and where we can go:

username@computer:~$ pwd
/home/username/
username@computer:~$ ls
Desktop  Documents  Downloads  Music  Pictures  Public  Templates  Videos
username@computer:~$ cd Desktop
username@computer:~/Desktop$ pwd
/home/username/Desktop/
username@computer:~/Desktop$ ls

username@computer:~/Desktop$

Notice that after we cd into the Desktop the command pwd now prints out:

/home/username/Desktop/

rather than:

/home/username/

In the beginning, there are no files in the Desktop directory, which is why the output of ls in this directory is empty.

We can move up one step in the directory tree (e.g., from /home/username/Desktop to /home/username or from /home/username to /home) by typing cd .. Here “up” is represented by “..” In this context, this command will move us up one level back to our home directory:

username@computer:~/Desktop$ pwd
/home/username/Desktop/
username@computer:~/Desktop$ cd ..
username@computer:~$ pwd
/home/username/

Notice that the current working directory is also shown in the prompt string.

~	shortcut for your home directory
.	shortcut for the current working directory
..	shortcut for one level up from your current working directory

The tilde (~) directory is the same as your home directory: that is, ~ is shorthand for /home/username. Here’s another useful shorthand: a single dot (.) refers to the current directory.

Usually when you use cd, you will specify what is called a relative path, that is, you are telling the computer to take you to a directory where the location of the directory is described relative to the current directory. The only reason that the computer knows that we can cd to Desktop is because Desktop is a folder within the /home/username directory. But, if we use a / at the beginning of our path, we are specifying an absolute path or one that is relative to the the “root” or top of the file system. For example:

username@computer:~$ pwd
/home/username/
username@computer:~$ cd /home/username/Desktop
username@computer:~/Desktop$ pwd
/home/username/Desktop
username@computer:~/Desktop$ cd /home/username
username@computer:~$ pwd
/home/username

These commands achieve the same thing as the ones above: we cd into Desktop, a folder within our home directory, and then back to our home directory. Paths that start with a / are known as absolute paths because they always lead to the same place, regardless of your current working directory.

Running cd without an argument will take you back to your home directory without regard to your current location in the file system. For example:

username@computer:~/Desktop$ cd
username@computer:~$ pwd
/home/username

To improve the readability of our examples, we will use $ as the prompt rather than the full text username@computer:~$ in the rest of this tutorial and, more generally, in the course going forward. Keep in mind, though, that the prompt shows your current working directory.

Pick Up the Tutorial Materials

For the remainder of this tutorial, we will need a series of files that you will use in certain examples and exercises. To fetch these files, run the following commands:

cd
wget -nv https://classes.cs.uchicago.edu/archive/2021/fall/12100-1/tutorials/tutorial-linux/cs121-linux-tutorial-files.zip
unzip cs121-linux-tutorial-files.zip

After you run these commands, your home directory will contain a cmsc12100 directory, which will in turn contain a tutorial-linux directory that has some files for us to play with. You will learn how to manipulate these files in the next section.

Exercises

Use pwd, ls, and cd to explore the tutorial files and to navigate to the tutorial-linux subdirectory. The next examples will assume that your current directory is the tutorial-linux directory.

Copy (cp), Move (mv), Remove (rm), and Make Directory (mkdir)

cp <source> <destination>	copy the source file to the new destination
mv <source> <destination>	move the source file to the new destination
rm <file>	remove or delete a file
mkdir <directoryname>	make a new empty directory

Sometimes it is useful to make a copy of a file. To copy a file, use the command:

cp <source> <destination>

where <source> is replaced by the name of the file you want to copy and <destination> is replaced by the desired name for the copy. An example of copying the file test.txt to copy.txt is below:

$ cp test.txt copy.txt

<destination> can also be replaced with a path to a directory. In this case, the copy will be stored in the specified directory and will have the same name as the source.

Move (mv) has exactly the same syntax, but does not keep the original file. Remove (rm) will delete the file from your directory.

If you want to copy or remove an entire directory along with its files, the normal cp and rm commands will not work. Use cp -r instead of cp or rm -r instead of rm to copy or remove directories (the r stands for “recursive”).

Warning

Running rm -r cannot be undone. If you want to remove the entire contents of a directory, make sure you’re certain before you use rm -r that you want to remove everything in the named directory.

Some useful terminology: the -r argument in cp -r or rm -r is known as a flag. Flags help determine the behavior of a program. In this case, the flag allows cp and rm to work with a directory tree, rather than just a single file. Most commands can accept a number of different flags; later in this tutorial, we’ll see how to look up the documentation for specific commands, where we will be able to see the list of supported flags in each command.

You can make a new directory with mkdir directoryname, where directoryname is the desired name for the new directory.

Print the contents of a file

cat <path-name>

print the contents of a file to the terminal

Sometimes, we may want to take a look at the contents of a file from the terminal, without opening the file in an editor. We can do this with the cat command. For example:

$ cat test.txt
Linux Tutorial - Test file
==========================

Name: Firstname Lastname

Later in the tutorial, we’ll see how to edit this file.

Exercises

Try the following tasks to practice and check your understanding of these terminal commands.

1. Copy test.txt to copy.txt and use ls to ensure that both files exist.

2. Move the file copy.txt to the name copy2.txt. Use ls to verify that this command worked.

3. Make a new directory named backups using the mkdir command.

4. Copy the file copy2.txt to the backups directory.

5. Verify that step (4) was successful by listing the files in the backups directory.

6. Now that we have a copy of test.txt in the backups directory we no longer need copy2.txt. Remove the file copy2.txt in the tutorial-linux directory.

7. Print the contents of the hello_world.py file.

It can be tedious (and, when you are tired, challenging) to spell directory or file names exactly, so the terminal provides an auto-complete mechanism to guide you through your folder explorations. To access this functionality simply start typing whatever name you are interested in the context of a command and then hit tab. If there is only one way to finish that term hitting tab will fill in the rest of the term, for instance, if we typed ls b and then hit tab it would automatically finish the word ls backups and then await our hitting enter. If there is MORE than one way to finish a term, like if we had another folder called backups-old, then hitting tab twice will cause the terminal to display all of the options available.

Training yourself to use auto-completion (aka tab completion) will save you time and reduce the inevitable frustration that arises from mistyping filenames when you are tired or distracted.

Man Pages

A man page (short for manual page) documents or describes topics applicable to Linux programming. These topics include Linux programs, certain programming functions, standards, and conventions, and abstract concepts.

To get the man page for a Linux command, you can type:

man <command name>

So in order to get the man page for ls, you would type:

man ls

This command displays a man page that gives information on the ls command, including a description, flags, instructions on use, and other information.

Each man page has a description. The -k flag for man allows you to search these descriptions using a keyword. For example:

man -k printf

This searches all the descriptions for the keyword printf and prints the names of the man pages with matches.

Learning how to read man pages is an important skill.

Exercise

By default, the ls command does not include files with names that start with a dot (.). The tutorial-linux directory contains a file that starts with a dot. Use man to identify the flag to use with ls to include this file when listing the contents of tutorial-linux.

Editing and running a Python Program

In this section, you will walk through the steps to edit and run a Python program. We’ll start with editing a text file.

Using an Editor

List the files in the tutorial-linux directory. You should see the following:

backups hello_world.py  my_echo.py  my-input.txt  test.txt

How do we view and edit the contents of these files? There are many high-quality text editors for Linux. We will use Visual Studio Code, which is good for writing code.

You can open a specific file, say test.txt, using the code command from the Linux command-line by typing:

code test.txt

When you run this command, you will get a new window that looks like this:

Specifically, you’ll see the following text:

Linux Tutorial - Test file
==========================

Name: Firstname Lastname

If the file is blank, quit code and ensure that the file test.txt exists in your local directory (use ls to list the files in your local directory). If it does not, use cd to navigate to the tutorial-linux subdirectory inside the cmsc12100 directory.

Note: somewhat counterintuitively, the menu bar for Visual Studio Code is at the top of the Browser window. You need to run your mouse over the name to see the menu options.

For now, we will use Visual Studio Code (code) in a very basic way. You can navigate to a particular place in a file using the arrow keys (or your mouse) and then type typical characters and delete them as you would in a regular text editor. You can save your changes using the save option in the file menu or use the keyboard shortcut Ctrl-s. To quit, you can use the file menu quit option or the keyboard shortcut Ctrl-q.

As an aside, you can also launch code from the application launcher: simply click the Application button (at the top left of your screen), type “code” in the input box, and then click on the Visual Studio Code icon. You can then use the file menu to navigate the correct file. As with the terminal application, you might want to pin the icon for launching Visual Studio Code to your launch bar (right click your mouse and choose the “Lock to Launcher” menu item.)

Exercises

Make sure that you are comfortable with this level of usage:

1. Add your name after Author: in this file

2. Save the file

3. Close and reopen the file in code and ensuring that your name is still there

4. Finally, close code.

Run a Python Program

python3 file.py

runs the python program file.py

In this class, you will learn Python. To run a Python program, use the command python3 and the name of the file that contains your program.

Use ls to verify that there there is a file named hello_world.py in your tutorial-linux directory. Now, run the program in hello_world.py by typing (don’t forget about auto-complete!):

python3 hello_world.py

This program is a very simple. It just prints “Hello, World!” to the screen.

Note

There are several variants of Python, including Python 2.7 and Python 3. We will be using Python 3 and the corresponding python3 interpreter. The CS machines have Python 2.7 installed as the default Python. As a result, the command python runs a version of Python 2.7. There are some differences between the two languages and Python 3 programs may not run properly using a Python 2.7 interpreter.

Edit and Run a Python Program

In this section you will modify and rerun the program in hello_world.py. This change is very simple but goes through all the mechanical steps needed to program.

Open the file hello_world.py with the command:

code hello_world.py

The file contains a single line of code:

print("Hello, World!")

Change this line so that it instead says “Hello ” and then your name. For example if your name were Gustav Larsson, the line would read:

print("Hello, Gustav!")

Do the following steps:

1. Save the file hello_world.py in Visual Studio Code (forgetting to save is a surprisingly common error)

2. Rerun the program using python3

Let’s reinforce the steps to programming in Python with the terminal:

1. Change your .py file with an editor

2. Save the file

3. Run the file with python3

Forgetting to save the file (step 2) is a very common mistake!

In addition to the command-line version of Python, programmers often use Jupyter notebooks and other interactive version of Python. We will be using ipython3, an interaction version of the Python interpreter, in this course. We’ll introduce it during the first week of the quarter.

Wild Cards (using an asterisk)

Sometimes when we enter a string, we want part of it to be variable, or a wildcard. A common task is to list all files that end with a given extension, such as .txt. The wildcard functionality, through an asterisk, allows to simply say:

$ ls *.txt

The wildcard can represent a string of any length consisting of any characters - including the empty string.

It is important to be careful using wildcards, especially for commands like rm that cannot be undone. A command like:

$ rm *             ### DO NOT RUN THIS COMMAND!

will delete all of the files in your working directory!

FYI, the text that follows a # on the linux command-line is assumed to be a comment and is ignored.

Exercises

1. Navigate to the cmsc12100 directory. What do you see when you run ls tutorial*? What about ls tutorial*/*.py?

Useful Keyboard Shortcuts

Used at the Linux prompt, the keyboard shortcut Ctrl-P will roll back to the previous command. If you type Ctrl-P twice, you will roll back by two commands. If you type Ctrl-P too many times, you can use Ctrl-N to move forward. You can also use the arrow keys: up for previous (backward), down for next (forward).

Here are few more useful shortcuts:

• Ctrl-A will move you to the beginning of a line.

• Ctrl-E will move you to the end of a line.

• Ctrl-U will erase everything from where you are in a line back to the beginning.

• Ctrl-K will erase everything from where you are to the end of the line.

• Ctrl-L will clear the text from current terminal

Play around with these commands. Being able to scroll back to, edit, and then rerun previously used commands saves time and typing! And like auto-completion, getting in the habit of using keyboard shortcuts will reduce frustration as well save time.

Running Commands Sequentially

It is often convenient to chain together commands that you want to run in sequence. For example, recall that to print the working directory and list all of the files and directories contained inside, you would use the following commands:

$ pwd
/home/username/
$ ls
Desktop  Documents  Downloads  Music  Pictures  Public  Templates  Videos

You could also run them together, like so:

$ pwd ; ls
/home/username/
Desktop  Documents  Downloads  Music  Pictures  Public  Templates  Videos

First, pwd is executed and run to completion, and then ls is executed and run to completion. The two examples above are thus equivalent, but the ability to run multiple commands together is a small convenience that could save you some time if there is a group of commands that you want to execute sequentially.

Note

The shell is generally pretty flexible about the amount of white space separating commands, arguments, etc., so it will run any of the following as well:

$ pwd;ls
$ pwd ;ls
$ pwd; ls
$ pwd       ;        ls

Working with Input/Output Streams

When you run a program (at the command-line or by clicking), the Linux operating system creates a new process for running the program. Every Linux process has an input stream (known as standard in) for providing input to a program and two output streams, one for regular output (known as standard out) and one for providing information about errors (known as standard error). In this section, you will learn how to use these streams to provide input to a program and to capture the output.

Redirection

The examples in this section will use commands that we’ve not yet discussed. Refer to the man pages for information about unfamiliar commands.

As we already know, commands like pwd and``ls``, and cat will print output to screen by default. Sometimes, however, we may prefer to write the output of these commands to a file. In Linux, we can redirect the output of a program to a file of our choosing. This operation is done with the > operator.

Try the following example and compare your output with ours:

$ cd
$ touch test-0.txt
$ ls > test-1.txt
$ cat test-1.txt
Desktop
Documents
Downloads
Music
Pictures
Public
Templates
test-0.txt
test-1.txt
Videos
$ echo "Hello World!" > test-2.txt
$ cat test-2.txt
Hello World!
$ cat test-2.txt > test-1.txt; cat test-1.txt
Hello World!
$ rm test-*

Two important things to note:

1. If you redirect to a file that does not exist, that file will be created.

2. If you redirect to a file that already exists, the contents of that file will be overwritten.

You can use the append operator (>>) to append the output of command to the end of an existing file rather than overwrite the contents of that file.

Not only can we redirect the output of a program to a file, we can also have a program receive its input from a file. This operation is done with the < operator. For example:

$ python3 my_echo.py < my-input.txt

(Change back to your tutorial-linux directory before you try this command.)

In general, all Linux processes can perform input/output operations through, at least, the keyboard and the screen. More specifically, there are three ‘input/output streams’: standard input (or stdin), standard output (or stdout), and standard error (or stderr). The code in my_echo.py simply reads information from stdin and writes it back out to stdout. The redirection operators change the bindings of these streams from the keyboard and/or screen to files. We’ll discuss stderr later in the term.

Exercises

1. Run my_echo.py as shown above.

2. Run my_echo.py again, but this time redirect the output to a file named output.txt. Check the contents of output.txt using an editor or by using the cat or more commands.

3. Run my_echo.py redirecting the input from test.txt and the output to output2.txt. Check the contents of output2.txt.

4. When you are done, remove output.txt and output2.txt.

By the way, if you run python3 my_echo.py without redirecting the input, it will patiently wait for you to type some input for it to echo. Once you type some input and hit return, the program will echo your input, and then resume waiting for input. It will continue to do so until you exit by typing Ctrl-d. Give it a try!

Piping

In addition to the ability to direct output to and receive input from files, Linux provides a very powerful capability called piping. Piping allows one program to receive as input the output of another program, like so:

$ program1 | program2

In this example, the output of program1 is used as the input of program2. Or to put it more technically, the stdout of program1 is connected to the stdin of program2.

As another more concrete example, consider the man command with the -k option that we’ve previously discussed. Let’s assume that you hadn’t yet been introduced to the mkdir command. How would you look for the command to create a directory? First attempts:

$ man -k "create directory"
create directory: nothing appropriate
$ man -k "directory"
(a bunch of mostly irrelevant output)

As we can see, neither of these options is particularly helpful. However, with piping, we can combine man -k with a powerful command line utility called grep (see man pages) to find what we need:

$ man -k "directory" | grep "create"
mkdir (2)            - create a directory
mkdirat (2)          - create a directory
mkdtemp (3)          - create a unique temporary directory
mkfontdir (1)        - create an index of X font files in a directory
mklost+found (8)     - create a lost+found directory on a mounted Linux second extended fil...
mktemp (1)           - create a temporary file or directory
pam_mkhomedir (8)    - PAM module to create users home directory
update-info-dir (8)  - update or create index file from all installed info files in directory
vgmknodes (8)        - recreate volume group directory and logical volume special files

Nice.

Exercises

1. Use piping to chain together the printenv and tail commands to display the last 10 lines of output from printenv.

2. Replicate the above functionality without using the | operator. (hint: Use a temporary file.)

File Permissions

Sometimes we want to restrict who can access certain resources on the file system.

Most file systems assign ‘File Permissions’ (or just permissions) to specific users and groups of users. Unix is no different. File permissions dictate who can read (view), write (create/edit), and execute (run) files on a file system.

All directories and files are owned by a user. Each user can be a member of one or more groups. To see your groups, enter the command groups into the command line.

File permissions in Unix systems are managed in three distinct scopes. Each scope has a distinct set of permissions.

User - The owner of a file or directory makes up the user scope.

Group - Each file and directory has a group assigned to it. The members of this group make up the group scope.

Others - Every user who does not fall into the previous two scopes make up the others scope.

If a user falls into more than one of these scopes, their effective permissions are determined based on the first scope the user falls within in the order of user, group, and others.

Each scope has three specific permissions for each file or directory:

read - The read permission allows a user to view a file’s contents. When set for a directory, this permission allows a user to view the names of files in the directory, but no further information about the files in the directory. r is shorthand for read permissions.

write - The write permission allows a user to modify the contents of a file. When set for a directory, this permission allows a user to create, delete, or rename files. w is shorthand for write permissions.

execute - The execute permission allows a user to execute a file (or program) using the operating system. When set for a directory, this permission allows a user to access file contents and other information about files within the directory (given that the user has the proper permissions to access the file). The execute permission does not allow the user to list the files inside the directory unless the read permission is also set. x is shorthand for execute permissions.

To list information about a file, including its permissions, type:

ls -l <filepath>

You’ll get output of the form:

<permissions> 1 owner group <size in bytes> <date modified> <filepath>

For example, if we want information on /usr/bin/python3.8:

$ ls -l /usr/bin/python3.8
-rwxr-xr-x 1 root root 5486384 Jan 27  2021 /usr/bin/python3.8

First thing we can notice is that the owner of the file is a user named root. (FYI, root is a name for an account that has access to all commands and files on a Linux system. Other accounts may also have “root” privileges.) The file’s group is also root.

The permissions are -rwxr-xr-x. The initial dash (-) indicates that /usr/bin/python3.8 is a file, not a directory. Directories have a d instead of a dash. Then the permissions are listed in user, group, and others order. In this example, the owner, root, can read (r), write (w), and execute (x) the file. Users in the root group and all other users can read and execute the files.

By default, any files or directories that you create will have your username as both the user and the group. (If you run groups, you’ll notice that there is a group with the same name as your username. You are the only member of this group.) On our Linux machines, by default, new files are give read and write permissions to user and group and no permissions to other. New directories will be set to have read, write and execute permissions for user and group.

Exercise

1. Verify this claim by running ls -l backups/copy2.txt and ls -ld  backups in your tutorial-linux directory.

The -d flag tells ls to list the directory, instead of its contents. Notice that that the first letter in the permissions string for backups is a d, while it is a - for backups/copy2.txt.

Once you have verified the claim, go ahead and remove the backups directory.

Changing Permissions, Owner, & Group

chmod <permissions> <path-name>	set the permissions for a file/directory
chmod <changes> <path-name>	update the permissions for a file/directory
chown <username> <path-name>	change the owner of a file to username
chgrp <group> <path-name>	change the group of a file

To change permissions, we use the chmod command. There are two ways to specify the permissions. We’ll describe the more accessible one first: to set the permissions you specify the scope using a combination of u, g, and o, the permission using r, w, and x, and either + or - to indicate that you want to add or remove a permission. For example uo+rw indicates that you want to add read and write permissions for the user and others groups.

We can demonstrate this using the cat command:

$ echo "Hello!" > testfile
$ ls -l testfile
-rw-rw---- 1 username username 7 Aug 23 11:22 testfile
$ cat testfile
Hello!
$ chmod ug-r testfile   #remove read and permissions from user and group
$ ls -l testfile
--w--w---- 1 username username 7 Aug 23 11:22 testfile
$ cat testfile
cat: testfile: Permission denied
$ chmod u+r testfile    #give user scope read permissions

In this last example, we have added user read permissions to testfile.

In addition to the symbolic method for setting permissions, you can also use a numeric method: each permission has a unique value: read = 4, write = 2, execute = 1. As a result, you can describe the permissions of each scope using the sum of its permissions’ values. For example, if a file has read and write permissions for the user scope, its permissions can be described as 6 (4 + 2 = 6).

You can describe the permissions of a file overall using these values for each scope. For example, 761 describes the permissions for a file with read, write, and execute permissions for the user scope, read and write permissions for the group scope, and only execute permissions for the others scope.

The symbolic approach is relative: it allows you to add and remove permissions relative the the current file permissions. The numeric method is absolute: it sets the permissions to a specific configuration. We recommend starting the symbolic approach. It is easier to get right. As you get more comfortable with setting permissions, it is useful to learn how to use the numeric method.

To change the owner of a file or directory (if you are the owner or root), use the command:

chown <new owner> <path to file>

To change a file’s group (if you are the owner or root), use the command:

chgrp <new group> <path to file>

It is unlikely that you will need to use these two commands for this course.

Exercises

1. Run echo "Hello!" > testfile to construct testfile. Look at the permissions using ls -l.

2. Change the permissions on testfile to allow and read access for others. Run ls -l testfile to check the new permissions.

3. Remove group write access from testfile. Check the corrected permissions.

4. Remove testfile using rm.

Final Notes

Sometimes, a program will run indefinitely or misbehave. When this happens, you can type Ctrl-C to send an interrupt signal to the running program, which usually causes it to terminate. On occasion, you may need to type Ctrl-C a few times. As noted earlier, typing Ctrl-D sends an end of input signal, which tells the program that no more information is coming.

Log out

Clicking on the power button icon in the top right corner of the screen will give you a menu. To log out, choose “Power Off/Log Out” from this menu, choose Log out from the menu that pops up, and then click the “Log out” option in the widget that pops up (rather than the cancel option).

Make sure to always log out from your machine before you leave CSIL.
